Cutting Frequency (Times/min)

Al-plastic: 20-40 times/min

Al-Al: 6-20 times/min

Max. Production Capacity (Blister/h)

Al-plastic: 2400 (According to standard plate 80×57)

Al-Al: 1200 (According to standard plate 80×57)

Max. Forming Area and Depth (mm)

Al-plastic: 80×100×26  (Standard 70×90×14)

Al-Al: 80×100×14

Travel Range (mm)

20-80 (Can be manufactured as user’s requirements)

Air Pressure (Mpa)

0.4-0.6

Standard Blister size (mm)

80×57 (Can be manufactured as user’s requirements)

Power

380V/220V  50Hz  3.5kw

Main Motor Power (kw)

0.75

PVC Rigid Sheet (mm)

0.25-0.5×100

PTP Aluminum Foil (mm)

0.02-0.035×100

Dialysis Paper (mm)

50-100gx100

Mould Cooling

Tap Water or Circulating Water

Overall Dimensions (mm)

1400×460×950（L×W×H）

Weight (kg)

450
